NetPRO Battery – Front Terminal FT

AGM battery designed specifically for the telecom industry. Its sleek, slim shape and front terminal connection ensure effortless installation and maintenance, saving valuable space without compromising on performance.
With a unique radial grid design and precision assembly technology, this rechargeable battery delivers exceptional high-rate discharge performance, meeting the demands of critical telecom applications with ease.
Our front access battery is engineered to maintain electrolyte volume throughout its lifespan, eliminating the need for water addition and ensuring consistent performance over 8-10 years of standby operation at 25 degrees Celsius, thanks to its corrosion-resistant grid alloy.
Crafted from high-purity materials, this AGM battery boasts minimal self-discharge rates, guaranteeing reliable power even during extended periods of downtime.
Gas recombination technology makes this power supply device operates cleanly and efficiently, with no acid mist emissions, making it environmentally friendly and safe for indoor use.
The use of best-in-class sealing technology ensures that this UPS battery is perfectly sealed, providing high security and reliability.

Suitable for 19inch and 23inch power cabinet.

Used in telecom system including exchange board, microwave station, mobile base station, data center, radio and broadcast station.

Great for power supply system of private network or LAN.

Used as signal system battery and emergency lighting system battery.

Perfect for EPS and UPS system.

Solar and wind system.

Specification Download

CSPower Model	Nominal Voltage (V)	Capacity (Ah)	Dimension (mm)				Weight	Terminal
CSPower Model	Nominal Voltage (V)	Capacity (Ah)	Length	Width	Height	Total Height	kgs	Terminal
Front terminal 12V Sealed Free Maintenance AGM Battery
FT12-55	12	55/10HR	277	106	222	222	16.5	M6×16
FT12-80	12	80/10HR	562	114	188	188	25	M6×16
FT12-100	12	100/10HR	507	110	228	228	29.4	M8×16
FT12-105/110	12	110/10HR	394	110	286	286	30.5	M8×16
FT12-125	12	125/10HR	552	110	239	239	38	M8×16
FT12-150	12	150/10HR	551	110	288	288	44	M8×16
FT12-160	12	160/10HR	551	110	288	288	44.5	M8×16
FT12-175	12	175/10HR	546	125	321	321	53.5	M8×16
FT12-180	12	180/10HR	560	125	316	316	55	M8×16
FT12-200B	12	200/10HR	560	125	316	316	58	M8×16
FT12-200A	12	200/10HR	560	125	316	316	59	M8×16
Notice : Products will be improved without notice, please contact cspower sales for specification in kind prevail.
